Description
| Load Capacity | 1.5 T |
| Drive Motor Power | 48V / 1500W |
| Operation Type | Fully Electric Stand-On |
| Lifting Motor Power | 48V / 2200W |
| Braking System | Electromagnetic Brake |
| Fork Dimensions | 1150 × 190 × 60 mm |
| Net Weight | Approx. 610 kg (Standard Configuration) |
| Overall Fork Width | 700 mm |
| Fork Lowered Height | 90-160 mm |
| Inner Fork Width | 320 mm |
| Load Capacity | 2 T |
| Drive Motor Power | 48V / 2000W |
| Operation Type | Fully Electric Stand-On |
| Lifting Motor Power | 48V / 3000W |
| Braking System | Electromagnetic Brake |
| Fork Dimensions | 1150 × 190 × 60 mm |
| Net Weight | Approx. 650 kg (Standard Configuration) |
| Overall Fork Width | 700 mm |
| Fork Lowered Height | 90-160 mm |
| Inner Fork Width | 320 mm |
| Fork lifting height (2-stage mast) | Collapsed mast height |
| 2000mm | 1560mm |
| 2500mm | 1760mm |
| 3000mm | 2000mm |
| 3500mm | 2300mm |
| 4000mm | 2550mm |
| (Level 3 Door) | |
| 3500mm | 1800mm |
| 4000mm | 1960mm |
| 4500mm | 2100mm |
| 5000mm | 2330mm |
| 5500mm | 2500mm |
