Description
1. The vehicle has a compact appearance, a smallturning radius, and can work in narrow passages.
2. Light weight, energy-saving and convenient,and the control mechanism is flexible, reliable and
safe.
3.Standard solid tires, stronger load-bearingcapacity and life, and low maintenance costs.
4. Using batteries as the power source, purepower, no pollution, meeting nationalenvironmental protection requirements.
5. Equipped with advanced energy regenerationsystem, energy-saving and high efficiency, strongendurance.
| Model | CPD-35 |
| Lifting Height | 3000mm |
| Total Length(With Forks) | 3970mm |
| Total Length(Without Forks) | 2750mm |
| Total Width | 1200mm |
| Total Weight | 4200kg |
| Lifting Capacity | 3500kg |
| Total Height | 2130mm |
| Fork Length | 1070mm |
| Lifting Motor | 15kw |
| Walking Motor | 15kw |
| Min Turning Radius | 2050mm |
| Battery Capacity | 60V 450AH(customizable) |
| Tire Type | Solid tires |
