Description
1. Simple, elegant and beautiful appearance
2. New steering wheel adjustment mechanismimproves operating comfort and adjustmentreliability.
3. High-top large-diameter intake system designcan keep the engine away from dust, effectivelyexer: engine performance and increase life
4. Wide-view mast design makes the driver’s fieldof vision wider.
5. Reliable LCD digital special instrument andfriendiy human-machine interface make it easyfor the driver to accurately control the vehicle
status.
| Model | CPC25/CPCD25 |
| Rated lifting weight | 2500kg |
| Power form | Diesel |
| Max lifting speed(full load) | 400mm/h |
| Gradeability(full/empty) | 15/20% |
| Fork liting height | 3000mm |
| Minimum tumning radius | 2450mm |
| Overallsize | 3605x1160x2090mm |
| Working height | 4080mm |
| Wheelbase | 1640mm |
| Driving speed(full/unloaded) | 17/19km/h |
| Standard fork length | 1070mm |
| Engine model | XINCHAI 4D29V41 |
| Rated power | 36.8kw |
| Speed at rated power | 2550rpm |
| Speed change form | Mechanical/Hydraulc |
